FireFox® 2 C WinTech
FireFox® 2 C WinTech
Speak to our team about smarter, connected cordless riveting for your applications.
About FireFox® 2 C WinTech
The FireFox® 2 C WinTech is a powerful pneumatic-hydraulic blind rivet nut setting tool with integrated setting-process monitoring. Based on the proven TAURUS® C platform, it uses stroke and force sensors to analyse every installation and compare the result against a user-defined acceptance window.
A coloured LED provides immediate feedback, while setting results can be recorded and transferred through a data connection for quality control and traceability. The system can even detect incompletely installed blind rivet nuts, helping manufacturers reduce rejects, prevent costly non-conforming components and improve process reliability.
Delivering up to 22,000 N of setting force with a maximum 10 mm stroke, the FireFox 2 C WinTech is particularly suited to serial production, safety-critical components and automated setting processes.
Technical FAQs
What is the FireFox 2 C WinTech used for?
It is designed for setting blind rivet nuts while monitoring and documenting every installation. It is particularly suitable for serial production, automated processes and safety-critical components.
How does its setting-process monitoring work?
Integrated stroke and force sensors analyse the setting process electronically. Special software allows the user to define an acceptable setting window against which each installation is assessed.
How does the tool indicate whether a setting is acceptable?
A coloured LED on the tool displays the result immediately. The monitoring system can also identify incomplete blind rivet nut installations and other results that fall outside the defined acceptance window.
What are the main technical specifications?
The tool delivers a setting force of 22,000 N at 6 bar, has a maximum stroke of 10 mm and operates at an air pressure of 5-7 bar. It weighs approximately 3.1 kg and consumes around 2-4 litres of air per setting.
Which blind rivet nut sizes can it install?
Depending on the material, the FireFox 2 C WinTech covers sizes from M4 to M12. It handles aluminium from M5-M12, steel from M4-M12, and A2 or A4 stainless steel from M4-M10.
